Table 33: LED 1 - top
GPO2 GPO1
Yellow 0 0
Green 0 1
Red 1 0
Off 1 1
Table 34: LED 2 - middle
GPO4 GPO3
Yellow 0 0
Green 0 1
Red 1 0
Off 1 1
Table 35: LED 3 - bottom
GPO6 GPO5
Yellow 0 0
Green 0 1
Red 1 0
Off 1 1
9.2 General Purpose Output Off
Syntax Hexadecimal 0xFE 0x56 [Num]
Decimal 254 86 [Num]
ASCII 254 “V” [Num]
Parameters Parameter Length Description
Num 1 GPO number.
Description This command turns OFF general purpose output [num].
NOTE OFF means that the output is pulled LOW.
Remembered Yes
