5.4 Font Metrics
Syntax Hexadecimal 0xFE 0x32 [lm] [tm] [csp] [lsp] [srow]
Decimal 254 50 [lm] [tm] [csp] [lsp] [srow]
ASCII 254 “2” [lm] [tm] [csp] [lsp] [srow]
Parameters Parameter Length Description
lm 1 Left margin: Location in pixels.
tm 1 Top margin: Location in pixels.
csp 1 Character Spacing: Amount of
space in pixels between characters.
lsp 1 Line Spacing: Amount of space
between lines in pixels.
srow 1 Scroll Row: The Y location of the
last row in pixels.
Description Font metrics define where the characters are positioned on the screen,
by setting where the rows and columns begin based on the
[lm][tm][csp][lsp][srow] parameters. [lm] defines the leftmost position
and [tm] the topmost. [csp] controls the amount of pixels that are placed
in between characters and [lsp] controls the amount of pixels that are
placed in between lines. [srow] is the location of the top of the last row
that will be displayed on the GLK19264-7T-1U. It defines the row that,
when filled, will cause the display to auto scroll if auto scrolling is
enabled. The font metrics will have to be reconfigured after changing to
a different font.
Remembered Yes
5.5 Set Box Space Mode
Syntax Hexadecimal 0xFE 0xAC [value]
Decimal 254 172 [value]
Parameters Parameter Length Description
value 1 Value (0: Off, 1: On)
Description This command will toggle the box space mode. Box space mode is
when a box, the size of the character to be written, is printed to the
display before a character is written.
Remembered Yes
Default On
