9.3 General Purpose Output On
Syntax Hexadecimal 0xFE 0x57 [Num]
Decimal 254 87 [Num]
ASCII 254 “W” [Num]
Parameters Parameter Length Description
Num 1 GPO number.
Description This command turns ON general purpose output [num]. The standard
GPO’s on the GLK19264-7T-1U output 20mA of current at 5V.
NOTE ON means the output is pulled HIGH.
Remembered Yes
9.4 Set Startup GPO state
Syntax Hexadecimal 0xFE 0xC3 [Num] [state]
Decimal 254 195 [Num] [state]
Parameters Parameter Length Description
Num 1 GPO number.
state 1 Startup state (0: Off, 1: On)
Description This command will set the startup state for the GPO on the next power
up. A value of one will cause the GPO to be off on the next startup
while a value of one will cause the GPO to be on.
NOTE This command does not affect the current state of the GPO.
Remembered Always
10 Keypad
10.1 Introduction
The GLK19264-7T-1Usupports up to a 7 Key, matrix style, embedded keypad and may be configured
to allow key presses to be automatically transmitted via RS-232 or polled through I 2 C. The GLK19264-7T-
1U also allows for auto-repeating key presses. The keypad is scanned whenever a key is pressed;there is
no continuous key scan. This means that key presses are dealt with immediately without any appreciable
latency. This also prevents electrical noise which is often caused by continuous key scans.
The keypad is tactile with seven keys. The value of each key is listed in the table below.
