• The indicated value which is blinking is integrated during the "blink"

display at the time of momentary flow rate display span OVER.

Flow Measurement/Square Root Extraction Mode

No.

Setting Item

LCD Display

Setting Description

Setting Range

Default

Display mode

n

~

roT

Selection for flow measure-

ment/ square root extraction

mode

non: Differential pressure

display mode Lin: Linear

display mode Rot: Square

root display mode

non

Maximum

differential

selection

1

p. 400

Maximum differential pres-

sure relating to the flow rate

25 to 100% F.S. of sensor

range

100.0%

of sensor

range

Flow rate deci-

mal pt. position

D 0

Displays of value after deci-

mal point, # of digits

0,1,2,3 digit

0

Max. momen-

tary flow

D 1000

Max. momentary of flow

using arbitrary units

0 to 1999

1000

Low cut

l 0.0

Forces display and output to

zero

0.0 to 30.0% F.S. of max.

display span

0.0

Output zero

point

2

A 0.0

Momentary flow rate of ana-

log output zero point (4mA):

100.0% F.S.

–10 to 100% F.S. of max.

display span

0.0

Output span

point

2

A100.0

Momentary flow rate of ana-

log output zero point

(20mA): 100.0% F.S.

–10 to 100% F.S. of max.

display span

100.0

Time factor

U SE[

Measurement of max. mo-

mentary flow rate over time

selected

Seconds, minutes or hours

Sec

k

21

Flow rate vol-

ume factor

U 1

Flow rate x time selected

1,10,100,1000

1

k

22

Display

switch set-

ting

s bT

Selection of display switching

method of momentary flow

rate and integrated volume

ti = automatic

bt = manual

bt

k

23

Switch time

interval

T 5

Selection for ti: automatic

Displays switching time in-

terval in seconds

1 to 10 seconds (10 stage)

5

k

24

Loop check

3

c 0.0

Output check using arbitrary

value – displays pressure

correlating to the 4 to 20mA

signal

Display: momentary flow

rate display span

Analog output: 4 to 20mA

0.0 to 100.0%

0

(4.0mA)

(1) In the setting of a differential pressure the decimal point position is fixed for each differential pressure range.

The max. differential pressure can be set from the value which is 25%F.S of the differential pressure range above the
minimum differential pressure.The values under 25%F.S. cannot be increased or decreased by T, S key.

(2) For setting zero point and span point of the analog output, input the percent value over the maximum display span (be-

tween OFFSET and FULL SCALE). Its decimal point position can be set up to one digit after the decimal point (xx.x).

(3) Regardless of generated differential pressure or low-cut, the loop check can be changed arbitrarily linking the

momentary flow rate display with the analog output using the T, S keys. This example of LCD display shows
the display set to span point.
