12
Table 1: FIGURE 1 (FRONT PANEL) DESCRIPTIONS
FRONT PANEL VIEW DESCRIPTIONS
1 COLD START – DC start switch 16 SB4 – Signal Circuit Breaker 4, 5A
2 COLD START INDICATOR 17 SB5 – Signal Circuit Breaker 5, 5A
3
ALARM SILENT/TEST – Dual
function switch
18 SB6 – Signal Circuit Breaker 6, 5A
4
ALARM SILENT/TEST
ACKNOWLEDGE INDICATOR
19 EQUIP – Equipment Circuit Breaker, 15A
5 SYSTEM ON/OFF SWITCH 20 MCB – Main Circuit Breaker, 30A
6 LCD DISPLAY 21 BATTERY TEST POINTS
7 SELECT/MENU MODE 22 GFI RECEPTACLE
8 ENTER/SHOW TIME 23 BYPASS SWITCH
9 UP ARROW + 24 AUTO/FLASH SWITCH
10 DOWN ARROW - 25 F1 – 24VDC Output Fuse, 7A
11
FL1 – Flash Circuit Breaker 1 –
10 Amp
26 F2 – 24VDC Input Fuse, 3A
12
FL2 – Flash Circuit Breaker 2 –
10Amp
27 24VDC Test Points
13
SB1 – Signal Circuit Breaker 1,
5A
28 24VDC Indicator LED
14
SB2 – Signal Circuit Breaker 2,
5A
29 MODEL 204 FLASHER UNIT #1 SLOT
15
SB3 – Signal Circuit Breaker 3,
5A
30 MODEL 204 FLASHER UNIT #2 SLOT
