88
89
About HD Radio™ Technology
• Program Service Data provides song name, artist,
station ID, and other relevant data streams
• Adjacent to traditional main stations are HD2/HD3
Channels, providing new original formats on the
FM dial
• Bookmark is a music & product discovery feature
that enables users to store information about
content on the radio and delivers interactive
information via QR codes
• HD Radio broadcasts deliver crystal clear, CD-like
digital audio quality to consumers
• iTunes® Tagging provides users the means to
“tag” broadcast radio content for later review and
purchase from the iTunes Store
• Visual images, such as album art of over-the-air
broadcasts from HD Radio stations
ñ
HD
Radio™ tuner Operation
HD Radio tuner Basic Operation
Most functions can be controlled from the source control screen.
NOTE
• Set the remote controller mode switch to AUD mode before starting operation, see
.
Simple Control screen
List Control screen
2
6
2
7
1
7
3
3
4
4
5
8
1 PS/Station name display
Displays the PS name or station name.
2 Information display/Control switching area
Displays the following information.
• Picture: The picture data or station Logo data is displayed if available from current content.
• [FM1] etc.: Band display
• MHz/kHz: Frequency display
• Preset #: Preset number
• HD#: Channel display
Touch to switch between the Simple Control and List Control screen.
3 Multi function key
Touch to switch the multi function menu. For details on the menu, see
4 Preset key/Multi function menu
Recalls the memorized station or channel. When touched for 2 seconds, stores the current receiving
station or channel in memory.
When switched, various functions can be performed by using keys in this area.
For details on the menu, see
5 Sub function key
Touch to display “Sub function menu” (7 in this table).
Continued
