Operating and installation instructions
Thrust actuator ARI-PREMIO
5.5.13.3 Technical data – DC module
Type PREMIO-24V DC
Thrust force kN 2.2 5 12 15
Travel distance mm 50 80
Duty classification in accordance with
EN 60034 S3 80% DC 1200 c/h
Control speed mm/s 0.38 1.00 0.38 0.79 0.38
Supply voltage 24V DC ± 10% BLDC motor
Power consumption VA 7 14 30 Max. 72
Protection to DIN 60529 IP65
Storage temperature °C -40°C ... +85°C
Max. permissible ambient
temperature °C -20°C ... +70°C
Handwheel Yes (rotating during operation) Yes (engageable)
Operation: 3-step: 24V DC/AC or 90 to 253V AC
Pole changing for 24V DC (with optional board support)
Max. conductor cross-sections Supply voltage: 2.5mm²
3-step input: 2.5mm²
Control signals: 2.5mm²
Mounting position Any, exception: the motor must not be suspended downwards
Gear lubricant Klüber Isoflex Tobas NB152 Molyduval Valenzia H2
Weight kg 5.4 6 10.5
Accessories
Electronic position controller
Type ES11 - For control with 0(2)...10V or 0(4)...20mA;
electrical isolation between mains voltage and control signal
- Incl. potentiometer
Electronic position indicator Type RI22 - Analogue output for position feedback 0(4)...20mA, optional
switching to 0(2)-10V, output can be inverted; electrical isolation
between mains voltage and position feedback signal
- Optional display (for indicating position feedback signal in mA or V)
- Incl. potentiometer
Potentiometer Conductive plastic
max. 2 pcs. 500, 1000, 2000, 5000 ohm; 1 W
Wire‚ Äö
max. 2 pcs. 100, 200 ohm; 1 W
Contactless
max. 1 pc. Only in conjunction with RI22
Feedback signal corresponds to RI22
Board support for pole changing at
24V DC For 3-step control with pole changing (two-wire circuit). The direction of motor rotation is
changed by reversing the supply voltage
2 additional intermediate position
switches S4, S5
Information:
Gold contacts should be used for low
switching capacities and aggressive
atmosphere. Standard Zero potential, switching capacity 10A, 250V~
Low-voltage Zero potential, with gold contacts, max. switching capacity 0.1A,
4-30V
Battery-operated emergency reset
(available from 2012 approx.) - Mounted to the outside of the actuator
- In the event of a power failure, the actuator is moved into a defined end position (extending
or retracting) by battery power
- Battery capacity after one year without recharging: > 85%
- Sufficient battery capacity for at least 5 runs
