Operating and installation instructions
Thrust actuator ARI-PREMIO
5.4.3 Connection
To connect the thrust actuator up to the electrical power supply, proceed as follows:
- Run the thrust actuator a few mm out of the lower final position applying the manual mode.
- Loosen collar nut / countersunk screw on hood, carefully remove hood in upward
direction.
- Remove blind plug fom the cable connection.
- Insert the connection line through this cable inlet until sufficient conductor length is
available up to the corresponding terminals; then tighten the cable connection until the
connecting cable is clamped in place inside it.
- Strip connecting cable approx. 1-1.5 cm above cable inlet.
- Strip the individual conductors approx. 5mm away from the end and fit with conductor end
sleeves.
- Connect protective conductor of connecting cable up to protective conductor terminal of
thrust actuator.
- Connect neutral N/MP conductor of connecting cable up to terminal 1/N of thrust-actuator
terminal strip.
- Connect pulse line for move-out connecting rod up to terminal 11 of thrust-actuator
terminal strip.
- Connect pulse line for move-in connecting rod up to terminal 14 of thrust-actuator terminal
strip.
- Place hood on carefully from above and mount firmly onto thrust actuator with collar nut /
countersunk screw and rubber gasket.
- Connect supply line to mains and run thrust actuator to each of the final positions so as to
check whether the final-position travel switches effect switching off, also checking to see
whether the direction of movement on the thrust actuator corresponds to the desired
direction.
- If the directions of movement are contrary to those desired, the pulse lines governing the
move-in and move-out connecting rod will need to be exchanged.
ATTENTION !
- Work on electrical systems or equipment must only be carried out by qualified
electricians or by trained individuals under the guidance and supervision of a
qualified electrician in compliance with regional electrical requirement and
regulations.
- When connecting the thrust actuator the supply line must be disconnected from
the mains (not live) during connection work. It must be impossible to switch the
power on unintentionally while the mains are disconnected in this way. Failure
to comply may result in death, serious injury or substantial damage to property.
