Red Lion LDSG - Manual (Page 13)

13 13
6-SPt
ACt-n
Setpoint
Select
SPSEL
Setpoint
Value
SP-n
Setpoint
Assignment
Src-1
Output
Logic
out-n HYS-n
Setpoint
Hysteresis
tON-n
On Time
Delay
Off Time
Delay
tOF-n
Standby
Operation
Stb-n
Reset
Action
rSt-n
PAR
Pro
Setpoint
Action
LIt-n
Setpoint
Annunciators
6.6 Module 6 - s
etpoInt
(a
larM
) p
araMeters
(

)
PARAMETER MENU
Enter the setpoint (alarm output) to be programmed. The  in the following
parameters will reflect the chosen setpoint number. After the chosen setpoint is
completely programmed, the display will return to
 
. Repeat step for
each setpoint to be programmed. The

chosen at

will return to
 
.
The number of setpoints available is setpoint output card dependent.
  




SETPOINT SELECT
 = Setpoint always off, (returns to SPSEL NO)
 = Absolute high, with balanced hysteresis
 = Absolute low, with balanced hysteresis
 = Absolute high, with unbalanced hysteresis
 = Absolute low, with unbalanced hysteresis
 = Deviation high, with unbalanced hysteresis *
 = Deviation low, with unbalanced hysteresis *
 = Outside band, with unbalanced hysteresis *
 = Lower Totalizer absolute high, unbalance hysteresis**
 = Upper Totalizer absolute high, unbalance hysteresis**
* Deviation and band action setpoints are relative to the value of setpoint 1.
It is not possible to configure setpoint 1 as deviation or band actions. It is
possible to use setpoint 1 for an absolute action, while its value is being used
for deviation or band.
** The lower Totalizer action

allows setpoints to function off of the
lower 5 digits of the Totalizer. The upper Totalizer action

allows
setpoints to function off of the upper 4 digits of the Totalizer. To obtain
absolute low alarms for the Totalizer, program the

or

output
logic as reverse.
Enter the action for the selected setpoint (alarm output). See Setpoint Alarm
Figures for a visual detail of each action.
SETPOINT ACTION




    
    
Setpoint Alarm Figures
With reverse output logic  , the below alarm states are opposite.
ALARM
STATE
OFF
ON
Hys
SP + Hys
SP
OFF
TRIGGER POINTS
ALARM
STATE ON OFF
Hys
SP1 + (-SPn)
SP1
ON
TRIGGER POINTS
Absolute Low Acting (Unbalanced Hys) = 
Deviation High Acting (SP < 0) = 
ALARM
STATE
OFF
ON
Hys
SP + ½Hys
SP
SP - ½Hys
OFF
TRIGGER POINTS
ALARM
STATE
OFF
ON
Hys
SP1 + SPn
SP1
OFF
TRIGGER POINTS
ALARM
STATE ON OFF
Hys
SP1 - (-SPn)
SP1
ON
TRIGGER POINTS
Absolute Low Acting (Balanced Hys) = 
Deviation High Acting (SP > 0) = 
Deviation Low Acting (SP < 0)= 
ALARM
STATE
OFF
ON
Hys
SP
SP - Hys
OFF
TRIGGER POINTS
ALARM
STATE
OFF
ON
Hys
SP1 - SPn
SP1
OFF
TRIGGER POINTS
ALARM
STATE
OFF ON
Hys
SP1 - SPn
SP1
OFF
SP1 + SPn
ON OFF
Hys
TRIGGER POINTS
Absolute High Acting (Unbalanced Hys) = 
This is also for Totalizer alarms: 
,  Deviation Low Acting (SP > 0) = 
Band Outside Acting = 
ALARM
STATE
OFF
ON
Hys
SP + ½Hys
SP
SP - ½Hys
OFF
TRIGGER POINTS
Absolute High Acting (Balanced Hys) = 
For maximum input frequency, unused Setpoints should be configured for

action. The setpoint assignment and the setpoint action determine certain
setpoint feature availability.
