6.
When prompted “Where do you want to install the boot loader? ” in the “Boot
Loader Configuration” dialog, select “Master Boot Record (MBR)” to instruct the
system be to boot from the RocketRAID 2240.
Continue the installation as normal. You can refer to Red Hat Enterprise Linux installa-
tion guide.
Note:The system device mapping order is the same as the order shown in
RocketRAID 2240 BIOS Setting Utility. If no other SCSI adapters are installed, the
device marked as “BOOT” or “HDD0”will identified as /dev/sda, “HDD1” as /dev/sdb,
“HDD2” as /dev/sdc, etc. When creating mount points, /boot must be mounted on /
dev/sda.
2 - Installing the RR2240 driver for an Existing System
Note: If a SCSI adapter is used to boot the system, make sure the RR2240 controller
BIOS loads/posts after the SCSI adapter’
s BIOS. It may be necessary to move the
adapter(s) to another PCI slot.
Step 1 Obtain the Driver Module
Extract the module file from the file modules.cgz (from the driver disk) using the
following commands:
# mount /dev/fd0
# cd /tmp
# gzip -dc /mnt/floppy/modules.cgz | cpio -idumv
Driver modules for all supported kernel versions will be extracted. The driver module
for the active kernel is located under the directory that matches the kernel version (/
tmp/‘uname –r‘
/hptmv6.o).
