HighPoint RocketHybrid 1222 - Manual (Page 39)

12 – MSU: Monitoring Hybrid Drives
This section describes monitoring options for Hybrid disks, including Event Notification and alarms.
12.1 - Receiving Email Event Notifications
This section describes the procedure to configure MSU to send event notifications to a user’s email account.
Note: This requires a working SMTP email server.
To configure email event notifications
1. Select Email Notify Setting, as shown in Figure 4-7.
2. Configure the email server settings and select Test setting, as shown in Figure 4-7.
MSU sends a test email to the configured email address. If the test email is received, the settings are
working correctly.
4. Select Submit to save settings. MSU confirms changes with the message Setting updated
successfully!
Figure 4-7 Email Notify Setting
12.2 - Viewing Events using Windows Event Viewer
Note: Because adapter events are triggered by the Windows driver, MSU events can also be viewed in the
Windows Event Viewer.
To view events in the Windows Event Viewer
1. From the Start menu, right-click My Computer (in XP or 2003) or Computer (in Vista, 2008,or 7) and
select Manage.
The Computer Management utility appears, as shown in Figure 4-8.
38
