HighPoint RocketHybrid 1222 - Manual (Page 29)

https://ip_adress:8443/MSU/JumpPage.php?Target=LoginPage
Note: Replace ip address with the IP address of the remote RAID controller. Alternatively, you
can use the System Name instead of the IP address in most internal network environments.
9.2 - Tray Application for Windows
When MSU opens in Windows, the Tray Application appears in the System Tray, as shown
in Figure 2-9.
Figure 2-9 Tray Application
The Tray Application provides right-click menu options for controlling the MSU, as shown in
Figure 2-10. The menu has options for performing the following tasks:
• Accelerate Status
• Open MSU
• Enable/Disable Alarm
• Enable/Disable Pop-up Event Messages
• View Version Information
•
Exit MSU
Figure 2-10 Tray Application: Right-click Menu
9.2.1 - Accelerate Status
Select Accelerate Status to see a pop-up window that displays the status of a scheduled acceleration task,
as shown in Figure 2-11.
Figure 2-11 Tray Application: Accelerate Status
28
