6 - Erasing Hybrid Configuration Data
This topic describes the procedure to erase Hybrid configuration data (if any) on a foreign
physical disk.
Note: The RocketHybrid 1220/1222 stores Hybrid configuration data on all physical disks that are part of a
virtual disk. This configuration data must be erased from each physical disk before they can be used to
create another virtual disk.
To erase Hybrid configuration data
WARNING If the physical disk was originally part of another virtual disk, using Erase RAID
Configuration Data may damage that virtual disk.
1. In the Topology pane, select Physical Disk (Test > HDD 0: WDC WD1002FAEX in Figure 1- 10
and press Enter. A menu pops-up, as shown Figure 1-10.
2. Select Erase RAID Config Data to erase the RAID configuration data, as shown in
Figure 1-10.
3. Select Yes to confirm the operation.
Figure 1- 10 Erase Configuration Data
Test 2FAEX
Free Physical Disks
21
