9 – MSU Overview
MSU is a browser-based management utility for the RocketHybrid 1220/1222 host adapters.
It can create and manage Hybrid Drives, using storage and enclosure devices connected to the host adapter.
This section provides an overview of MSU’s user interface.
9.1 - Opening MSU
This section discusses the following:
• Opening MSU in Windows
• Tray Application for Windows
9.1.1 - Opening MSU in Windows
This section describes the procedure to open MSU in Windows.
To open MSU in Windows
1. Verify that Active Scripting or JavaScript is enabled in the default browser, as described in
9.1,
Enabling Scripting .
2. Open MSU.
The MSU can be opened using any of the following methods:
•
Double-click the desktop shortcut for MSU, as shown in Figure 2-8.
Figure 2-8 MSU Desktop Shortcut
OR
• Right-click the desktop shortcut for MSU, and select Open.
OR
• Double-click the MSU Tray Application icon.
OR
• Right-click the MSU Tray Application icon, and select Open MSU.
3. Upon opening, the Login page appears, as described in 2.5, Login .
To control a local 88SE91xx controller
4. By default, MSU uses the following URL to select the default local 88SE91xx controller (if
any) installed on the local system.
https://localhost:8443/MSU/JumpPage.php?Target=LoginPage
Note: If MSU does not open the login page, replace localhost in the URL with the IP address
of the local controller (127.0.0.1).
To control a remote RAID controller
5. Type the following URL the browser address bar.
