MPEG-4 Video Server
4.2. Specifications
Models Video Server
Power Input DC 12V, 200 mA, provide another output interface
for external usage.
Network interface Ethernet 10BaseT/100BaseTX, Auto-MDIX, RJ-45
Video interface 1 analog video input and 1 analog video output
CVBS composite, BNC connector,
1.0Vp-p with 75 ohm loading
Serial interface 1 RS-485 interface for pan/tilt control, support Pelco-P
and Pelco-D protocol.
D/I D/O interface 1 D/I for alarm detection
1 D/O for alarm triggering
Micro-SD card interface Micro-SD card interface for local video storage
The supported Micro SD-Card capacity is up to 16G
bytes.
Rest button interface One reset button interface, to factory default settings
Led Indicator interfaces 1 LED interface for internet connection status indication
1 LED interface for Ethernet connection indication
Enable/disable – web configurable
Processors RISC CPU, hardware video processing and
compression.
Video compression MPEG-4 Part 2 (ISO/IEC 14496-2) with motion
detection.
profiles: Simple Profile, level 0-3
Frame rate Up to 30 fps in all resolutions
Video streaming MPEG-4
Separate frame rate/resolution/bandwidth settings for
PC and mobile.
Video settings Resolution: D1(720x480 for NTSC, 720x576 for PAL),
CIF(352x240 for NTSC, 352x288 for PAL),
QCIF(176x120 for NTSC, 176x144 for PAL)
Bandwidth : 64k, 128k, 256k, 512k, 768k, 1M, 1.2M,
1.5M bps
Frame rate : 1~5, 10, 15, 20, 25, 30 fps
