Page 9: Exhaust filter replacement
16
17
Release upper structure and lay flat. Pull exhaust filter cover tab
forward and remove exhaust filter cover and old exhaust filter.
1
4
up
do
wn
2
1
5
3
Pull old brush roll out of nozzle and dispose.
Locate end of new brush roll with recessed shaft. Insert this
end of brush roll into nozzle opening first. Turn counter-
clockwise to fully seat brush roll.
While pressing in brush roll release button, place brush roll
cover onto unit and snap into place.
Unplug before servicing.
1
Removing Nozzle Hose Blockages
up
do
wn
3
1
2
2
G
Brush Roll Replacement
Unplug before servicing.
Lay unit on side. Press brush roll release button, then pull
brush roll cover off unit.
1
1
3
2
3
While holding nozzle hose latch to the left, pull upper collar
of nozzle hose out of opening in bottom of upper structure.
Brush Roll Replacement
(cont.)
Lay unit over onto its front side. Press downward on latch to
open inspection door.
2
1
2
2
1
4
Grab rib on lower collar of nozzle hose and rotate to release
the lower end of the hose. Pull entire nozzle hose out through
upper opening. Remove blockage.
Install new exhaust filter. Reinstall exhaust filter cover by
snapping into place. Move upper structure back to upright
position.
up
down
3
4
1
2
2
G
C
up
down
2
1
3
3
Exhaust Filter Replacement
(cont.)
ENGLISH
