Rubbermaid 9VPHEF12 - Manual (Page 10)

18 19
Stand unit upright. While reinserting upper collar of nozzle hose
into opening on bottom of upper structure, push latch to right to
ensure secure connection.
Guide channel in lower hose collar onto post, and rotate to
lock into place. Close inspection door, snapping it into place.
up
do
wn
2
1
3
To reinsert brush roll, locate end of brush roll with recessed
shaft. Insert this end of brush roll into nozzle opening first.
Turn counter-clockwise to fully seat brush roll.
Remove brush roll from unit. Remove obstruction from brush
roll or nozzle opening.
While pressing in brush roll release button, place brush roll
cover onto unit and snap into place.
1
1
2
3
4
1
B
2
B
3
Remove upper hose by squeezing hose clip/pressing wand
release button. Remove blockage.
Reinsert upper hose into openings on upper structure/wand.
Push hose into openings until it snaps into place.
Hang upper hose onto hose hook.
Removing Upper Hose Blockages
Removing Upper Hose Blockages
(cont.)
Removing Brush Roll Obstructions
5
1
1
2
6
2
1
3
7
To reinsert nozzle hose, place the rib on the lower hose collar
in the lower right corner of the upper opening. Push hose fully
into nozzle.
Removing Nozzle Hose Blockages
(cont.)
ENGLISH
1
2
2
2
1
4
1
G
3
