- 19 -

9-1

9-2

9-5

English

Specifications (main kit IMU-100)

• Power source:

DC 24V

• Current consumption:

120 mA (standby) 780 mA (maximum)

• Operating temperature: 0

°C to 40 °C

• Communication:

Voice-actuated communication
Transmit output: 3 W 4

Receive output: 1.5 W 16

• Headset:

Ø3.5 plug
Impedance: 32

Rated input: 40 mW or more
Maximum input: 100 mW or more

• External speaker:

Impedance: 4 to 8

Rated input: 3 W or more
Maximum input: 6 W or more

• Paging speaker:

Impedance: 4 to 8

Rated input: 3 W or more
Maximum input: 6 W or more

• Material:

Steel plate

• Dimensions:

Main unit MU-100:
210 mm (width) x 45 mm (height) x

206 mm (depth)

Operation unit OU-100:
130 mm (width) x 49 mm (height) x

160 mm (depth)

• Weight:

Main unit MU-100:
Approx. 1.3 kg (2.87 lbs.)
Operation unit OU-100:
Approx. 700 g (1.55 lbs.)

English

Specifications (gooseneck microphone IME-100)

• Microphone:

Type: Condenser microphone
Directivity: Uni-directional
Input sensitivity: -46 dB

• Dimensions:

510 mm (length of gooseneck)

• Weight:

Approx. 190 g (0.42 lbs.)

Specifications (sensor ISE-100)

• Power source:

DC 24V

• Current consumption:

5 mA (standby) 13 mA (maximum)

• Operating temperature: 0

°C to 40 °C

• Material:

Aluminum

• Dimensions:

68 mm (width) x 50 mm (height) x
30 mm (depth)

• Weight:

Approx. 120 g (0.26 lbs.)

9-3

English

Specifications (acoustic interface kit IAI-100)

• Operating temperature: 0

°C to 40 °C

• Acoustic output:

Impedance: 4

Rated input: 4.5 W
Maximum input: 6 W

• Microphone:

Type: Condenser microphone
Directivity: Non-directional
Input sensitivity: -41 dB

• Material:

Aluminum
Speaker fixing plastic: ABS plastic fire

resistance 94V-0

• Dimensions:

Driver unit DR-100:
84 mm (width) x 150 mm (height) x
36 mm (depth)
Acoustic I/O tube AI-100:
27 mm (width) x 388 mm (height) x
24 mm (depth)

• Weight:

Driver unit DR-100:
Approx. 300 g (0.66 lbs.)
Acoustic I/O tube AI-100:
Approx. 400 g (0.88 lbs.)

9-4

English

English

9-6

Specifications (optional microphone IME-150)

• Microphone:

Condenser microphone, Non-directional

• Dimensions:

23 mm (width) x 115 mm (height) x
13 mm (depth)

• Weight:

Approx. 150 g (0.31 lbs.)

English

Specifications (acoustic tube IAX-100)

• Material:

Aluminum

• Dimensions:

27 mm (width)x 1,000 mm (height)x 24

mm (depth)

• Weight:

Approx.650 g (1.43 lbs.)

9

SPECIFICATIONS
