16
16. (fig16) Mark the remaining holes to be drilled in
the upper airspring and panhard frame mounts.
17. (fig17‐18) Now the airspring (F2107) can be
bolted into the upper and lower mounts.
Note. The lower bolt in the airspring may need to be
loosened to orientate the holes in the bags and
mounts.
18. Install fitting into airspring, make sure to use a
sealing agent Teflon tape or paste is the best.
Note. The fittings come with a anti seize on the
threads, this will not seal the airspring. Make sure to
use Teflon.
17
18
19
19. Install new shocks into stock location. This
completes the installation of the Airbar system into
your truck. If there is any additional help needed
please contact us Monday‐Friday 8am‐6pm eastern
time 812‐482‐2932 or
[email protected]
