5. (fig4) Now move to the axle bracket assembly.
Using bracket (A125‐2 ) it sits on top of the axle using
the pin to locate the bracket to the axle. The open
end of the bracket faces toward the cab of the truck.
The upper bar will be bolted here in another step.
Repeat this step for both driver and passenger side.
4
6. Using the supplied hardware (5/8 x 7” sae bolts,
washers and nyloc nuts) attach the lower axle
bracket (A125‐3L & A125‐3R) shown in (Fig 5 & Fig 6).
Note: There is a left and right side to the lower
bracket (a125‐3L) Make sure the lower round plate
goes under the frame rails.
5
6
7. (fig7)Now the bars are ready to be installed. Using
the factory front leaf mount bolt the new bar in seen.
Original leafspring bolts are used.
7
