Part # 19004900

4000lb. Air Over Leaf Kit – 2.5” Leaf / Side Frame


Components:

2

90006781

6.5” diameter double convoluted air spring

2

90000061

2.5” leaf spring bracket

2

90000070

Air spring roll plate

2

9000002

Upper bolt-on bracket

2

31954201

¼” npt x ¼” tube 90 degree airline fitting

Hardware:

2

99371001

3/8” x ¾” USS bolt

Air spring to lower bracket

2

99373005

3/8” lock washer

Air spring to lower bracket

6

99373003

3/8” SAE flat washer

Air spring mounting

4

99372002

3/8” USS Nylok nut

Air spring to upper brackets

8

99431002

7/16” x 1 1/4” USS bolt

Upper bracket to frame

8

99433002

7/16” USS flat washer

Upper bracket to frame

8

99432001

7/16” Nylok nut

Upper bracket to frame
