Part # 19003004
3000lb. Air Over Leaf Kit – 2.5” Leaf / Underframe
Components:
2 90009000 Tapered sleeve air spring
2 90000061 2.5” leaf spring bracket
2 90000070 Air spring roll plate
2 90000033 Under frame air spring bracket
2 31954201 ¼”npt x ¼” tube 90 degree airline fitting
Hardware:
6 99371001 3/8” x 3/4" USS bolt Air spring mounts
6 99373005 3/8” lock washer Air spring mounts
8 99371004 3/8” x 1 1/4” USS bolt Upper bracket to frame
8 99372002 3/8” USS Nylok nut Upper bracket to frame
14 99373003 3/8” flat washer Air spring mounts
