Ridetech 19002002 - Manual

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 19002002
2000lb Air Over Leaf Kit - 2.5” Leaf / Side Frame
Components:
2 90007076 Rolling sleeve air spring
2 90000061 2.5” leaf spring bracket
2 90000070 Lower air spring roll plate
2 90000002 Side frame upper air spring bracket
2 31952201 1/8” npt x 1/4 tube 90 degree air line fitting
Hardware:
2 99752004 3/4" SAE jam nut Air spring to upper bracket
2 99371003 3/8” x 1” USS bolt Air spring to lower bracket
2 99373003 3/8” flat washer Air spring to lower bracket
2 99373005 3/8” lock washer Air spring to lower bracket
8 99431002 7/16” x 1 ¼” USS bolt Upper bracket to frame
8 99432001 7/16” USS Nylok nut Upper bracket to frame
8 99433002 7/16” flat washer Upper bracket to frame
