Ridetech 11436799 - Manual (Page 5)

12
12. (fig12)Now the Panhard bar axle cover is ready to
be installed, just unbolt the top 5 bolts from the
rearend and replace with the supplied 3/8x1” bolts,
washers and lock washers.
13
13. (fig13)use the pahard bar as a guide to locate the
panhard frame mount these holes will also be used
for the upper airspring mount.
14
15
14. (fig14‐15) The upper airspring mount and
panhard frame mount will share a pre existing hole in
the chassis, this hole will capture the top hole
(fig15)of the airspring bracket and the middle
hole(fig14) in panhard bracket .
