Ridetech 11436799 - Manual (Page 4)

8
8. (fig8) Now Bolt the lower bar into the new axle
bracket assembly installed in step 5.
9. (fig9) Now Bolt the upper bar into the new upper
bar mount using the supplied 5/8x4.5”sae bolts, nuts,
and washers. 9
10. (fig10) Now Bolt the upper bar into the Axle
bracket assembly using the supplied 5/8x4.5”sae
bolts, nuts, and washers. 10
11. (fig11) This bracket must be removed to install
the upper airspring bracket to the frame, just drill the
rivets out and remove.
11
