Nitrous Express DRAG-SPORTSMAN N2O - Manual (Page 8)

7
Davis Technologies TM-Drag-Sportsman-MAP V3 2010
If another type of sensor is used, check with the
manufacturer to
determine connections.
(IMPORTANT--The sensor must be capable of 15Khz
resolution!!)
3 Pin Connector (Input/Output)
1. Connect the pin marked “A” (BLUE wire) to
the Trans Brake wire. (Coming from the trans brake
switch)
2. Connect the pin marked “B” (YELLOW wire) to
the Nitrous Controller “Input 2” (RED wire).
3. Connect the pin marked “C” (PINK wire) to the
data system or a LED to indicate when the system is
making corrections. (12v+ output through a 1K
resistor)
This unit is designed specifically to
work with the Nitrous Express
Maximizer 3
