Installation
Installation of the system is very simple. It is very
important to make all connections correctly.
Improper installation could result in poor system
performance or damage to the unit.
Keep all wires away from any spark plug wires and
coils or other sources of electrical noise and heat.
The unit should be mounted away from any sources
of electrical noise or high heat. It can be easily
mounted using the mounting flanges on each side.
Make the connections as follows:
2 Pin Connector (power in)
1. Connect pin “A” (RED wire) to 12v positive.
2. Connect pin “B” (BLACK wire) to ground.
3 Pin Connector (Sensor)
1. Connect the pin marked “A” (RED wire) to the
red wire on the sensor (12v positive)
2. Connect the pin marked “B” (BLACK wire) to
the black wire on the sensor (ground).
3. Connect the pin marked “C” (WHITE wire) to
the white wire on the sensor. This wiring is for
sensors supplied by Davis Technologies.
