diagram 1 (on the previous page). If the post on horn cam is not at

10:30, grasp post and turn it until it is at 10:30. Once completed, your

column will be in sync.

IMPORTANT!!

Steering Wheels:

The top shaft of the column is the same as a

GM passenger car from 1969-94 (Van columns

& some truck columns are not the same as

passenger cars). Original wheels from these years

will bolt directly to the top of the column with no

modifications. An aftermarket wheel will require

an adaptor. Align the spline and horn cam on the top of the column with

those in the adaptor and slide it onto the column. A nut has been provided

with your steering column. The nut will secure the wheel to the top of the

column. The nut on the wheel should be torqued to 35 ft lbs.

Column Shift Linkage Installation:

At the bottom of your column you will notice a

lever. This is the shift lever where your linkage

will attach from the column to the transmission.

Note the 5/16 hole through the bushings, most

kits use a 5/16 bolt to secure the rod to the

column. Please follow the kit instructions for

the linkage, but make sure that no part of their

kit hits the metal portion of the lever, as it will

create a rattle in the column.

Need Further Assistance?

ididit inc. has been serving the rodding community since 1986 and we take

pride in our outstanding customer service. If you need further assistance,

feel free to call us at (517) 424-0577 during our normal business hours.

You can also email us at [email protected]. Go to www.ididitinc.com/

contact-us for hours of operation.

Need A Visual?

Go to www.ididitinc.com/videos to watch installation videos, tech tips &

more!
