Wiring your Column
This ididit steering column uses a standard 3 7/8-inch male connect.
However, some GM columns use a 4 ¼-inch male connector. Connectors
do not interchange and must be used in pairs. A mate to the 3 7/8 inch plug
is available through ididit. If you need to change this connector for any
reason the following schematic will be helpful.
Horn Button Wiring:
A horn may require two wires to properly function with an ididit column.
The center lug on the button should connect to a
horn wire, which is provided by ididit with your
steering column. This horn wire will slide into the
horn cam (white plastic tube sticking up on the
top of the column). If there is a second wire off to
the side it is probably a ground wire (check with
the horn button manufacturer to be sure). This
is normally used when an o-ring is used to hold
the button in place. The o-ring does not provide
sufficient ground, therefore, an additional wire
is provided to ground the horn button. If there is not a hole in adaptor to
ground to, use one of the puller holes with a short bolt to attach the wire to
the adaptor.
Synchronizing your Column
In order to insure proper functioning, this steering column must be installed
in sync with the rest of the steering system. Turn signal cancellation and
wheel position, as well as smooth steering operation depends on it. Although
not all of them may need adjustment, the complete table of steps required
3
