Page 4
53xxx* Black Replacement Tarp
1087* Bow End Assembly (1)
27540100 Bow End Extender (1)
27540300 Extender Spring (1)
35541400 Right Side Tapered Bow Plug (1)
35541500 Left Side Tapered Bow Plug (1)
54xxx-10* Cab Bow w/End Caps (1)
54xxx-11* Ctr Bow w/End Caps (1)
54xxx-12* Cab Ctr Bow (L/B only) w/End Caps (1)
54xxx-13* Tail Ctr Bow (L/B only) w/End Caps (1)
54xxx-14* Tail Bow w/End Caps (1)
54xxx-26* Clamp Pack (set of 2)
21540301 Adjusting U-clamp w/hole (1)
25000400 1/4”-20 x 1” SHCS (1)
25005200 1/4”-20 x 2.5” Hex (1)
25005400 1/4”-20 x 4” Hex (1)
26001000 1/4”Plastic Acorn Nut (1)
26001100 1/4"Jam Nut (4)
54xxx-35* Cabrail Replacement Assembly
32540366 Cab/Tail Rail Seal (1)
32540363 68" Black Foam Roll
1078 Cabrail Tarp Strap Assembly S/B (1)
1088 Cabrail Tarp Strap Assembly L/B (1)
25003500 1/4”-20x1/2” SHCS (1)
26003200 Weld Nut (1)
26005000 1/4" Washer (1)
54500100 Strap for S/B (1)
54540100 Strap for L/B (1)
1085R Right Side Cab/Tail Plunger Assembly
1085L Left Side Cab/Tail Plunger Assembly
27540200 Cab/Tail Rail Extender (1)
27540300 Extender Spring (1)
35540100 End Cap Clip (1)
35540400 Right Side Lrg Cab/Tail End Plug (1)
35540500 Left Side Lrg Cab/Tail End Plug (1)
35541000 Right Side Sm Cab/Tail End Plug (1)
35541100 Left Side Sm Cab/Tail End Plug (1)
1086 Slide Lock Assembly
25540100 Thumbscrew (1)
26003200 Weld Nut (1)
26005000 1/4" Washer (1)
27540500 Slide Lock (1)
54xxx-45 Tail Rail Replacement Assembly
32540163 Tail Rail Seal (1)
1085R Right Side Cab/Tail Plunger Assembly
1085L Left Side Cab/Tail Plunger Assembly
27540200 Cab/Tail Rail Extender (1)
27540300 Extender Spring (1)
35540100 End Cap Clip (1)
35540400 Right Side Lrg Cab/Tail End Plug (1)
35540500 Left Side Lrg Cab/Tail End Plug (1)
35541000 Right Side Sm Cab/Tail End Plug (1)
35541100 Left Side Sm Cab/Tail End Plug (1
)
Register your warranty at:
extang.com
Par ts List
54xxx-55* Side Rail Replacement Assembly (1)
32540297 Siderail Tarp Seal 8'
1076 Siderail Seal 8'
1082 Side Rail End Plugs (2)
1083 Bow Clip Assembly
25004400 1/4”- 20 x 1/4” SHCS (1)
26003300 Weld Nut (1)
35540600 Bow Clip (1)
1090 Passenger-side Rear Latch Assembly (1)
25004300 1/4”- 20 x 5/8” SHCS (1)
26003200 Weld Nut (1)
35540900 Pivot Block (1)
27480100 Latch Spring (1)
26007700 Clevis Hitch Pin (1)
26007900 Clevis Latch Pin (1)
27540600 Latch (1)
1091 Driver-side Rear Latch Assembly (1)
25004300 1/4”- 20 x 5/8” SHCS (1)
26003200 Weld Nut (1)
26007700 Clevis Hitch Pin (1)
26007900 Clevis Latch Pin (1)
27480100 Latch Spring (1)
27540700 Latch (1)
35540900 Pivot Block (1)
1092 Passenger-side Front Latch Assembly (1)
25004300 1/4”- 20 x 5/8” SHCS (1)
25005400 1/4”- 20 x 4” Hex Head (1)
26000300 1/4" Nut (1)
26003200 Weld Nut (1)
26007700 Clevis Hitch Pin (1)
26007900 Clevis Latch Pin (1)
27480100 Latch Spring (1)
27540800 Tension Spring (1)
27540700 Latch (1)
35480100 Stanchion (1)
35540900 Pivot Block (1)
1093 Driver-side Front Pivot Assembly (1)
25004300 1/4”- 20 x 5/8” SHCS (1)
25005400 1/4”- 20 x 4” Hex Head (1)
26000300 1/4" Nut (1)
26003200 Weld Nut (1)
27540800 Tension Spring (1)
35480100 Stanchion (1)
35540900 Pivot Block (1)
Miscellaneous
28001000
3/16" Hex Key (1)
NOTE: To order replacement parts, itʼs best to contact our Customer Service Department for assistance, to ensure getting the correct part for your vehicle
application. When ordering, xxx represents the 3 digit suffix, as referenced on the sales receipt or vehicle application list. Additional parts information can
be found on our website, at http://extang.com/how.html. Customer Service: 800-877-2588
*
Specify: Year, Make, Model,
Long-bed or Short-bed, Driver or
Passenger side.
Extang Corporation
5400 S. State Rd.
Ann Arbor MI 48108
734-677-0444, Fax: 734-677-8409
