Par ts list – Extang FullTilt General Installation (Snap style) User Manual
Page 6
5xxx-*
Black Replacement Tarp
8xxx-10S*
Cab Bow w/Bow Ends (1)
8xxx-11S*
Center Bow w/Bow Ends (S Bed) (1)
8xxx-12S*
Cab Center Bow w/Bow Ends (L Bed) (1)
8xxx-13S*
Tail Center Bow w/Bow Ends (L Bed) (1)
8xxx-14S*
Tail Bow w/Bow Ends (1)
8xxx-31*
Front Replacement Corner (2)
8xxx-32*
Rear Replacement Corner (2)
4208
Replacement Corner Pads (4)
8xxx-35*
Upper Pivot (Cab) Rail Assembly
2001 Cab Rail Foam Strip (30 ft.)
27005500 Cab Rail Hinge Lock (1)
8xxx-36*
Lower Pivot Rail
8003 Pivot Rail Foam Pad (2)
8xxx-37*
L Channel (for Toolbox Installation only)
2014 L Channel Seal
8xxx-45*
Tailgate Rail Assembly
2002 Tailgate Foam Strip (6 ft.)
8xxx-55*
Side Rail Assembly (1)
2014 Side Rail Foam Strip (8 ft.)
21221 Bow Clip w/Screw (2)
25000800 1/4"-20x3/4" SHCS (1)
26002700 Weld Nut (1)
8xxx-70*
"L" Rod (1)
8016 "L" Rod Bumper (1)
8xxx-72*
Shock Stand-off Assembly (1)
27005100 Shock Stand-off Bracket (1)
26000100 5/16 Nylon Nut
28005100 10mm Ball Stud (1)
26002700 Weld Nut (1)
8xxx-73*
Latch Stand-off Assembly (1)
Extang Corporation
5400 S. State Road
Ann Arbor, MI 48108
734 677-0444, Fax: 734 677-8409
Register your warranty at:
extang.com
Par ts List
*
Specify: Year, Make, Model,
Long-bed or Short-bed, Driver or
Passenger side.
8xxx-71*
Latch Assembly (1)
8004 Latch w/Sleeves
26002700 Weld Nut (1)8xxx-74*
Front Clamp Assembly (1)
25000100 5/16-18x13/4 SHCS (1)
26005000 1/4" Washer (1)
8xxx-75*
Rear Clamp Assembly (1)
25000100 5/16-18x13/4 SHCS (1)
26005000 1/4" Washer (1)
1041
Corner Brace Assembly (1)
27440200 Corner Brace
26003300 Weld Nut (1)
25001200 1/4"-20x3/8" SHCS (1)
8007 Gas Shock (1)
8010 Pull-Down Strap w/Fasteners
Miscellaneous
28001000 3/16" Hex Key (1)
28001300 1/4" Hex Key (1)
28001400 3/32" Hex Key (1)
33070100 Metal Rail Snaps (1)
20161 Tarp Snap Tool Kit (w/4 Tarp Snaps)
NOTE: To order, xxx represents the 3-digit application # (vehicle type) following the 1- or 2-digit prefix, as referenced on the vehicle
application list or sales receipt. Or call our Customer Service Department at 1-800-877-2588 for assistance.
