CMP PX2KX-REX User Manual
Cable gland types
INSTALLATION INSTRUCTIONS FOR
CMP CABLE GLAND TYPES PX2K-REX,
PX2KW-REX, & PX2KX-REX
FOR TERMINATION OF CABLES WITH WIRE BRAID, TAPE ARMOUR (STA/DSTA), STRIP ARMOUR &
SINGLE WIRE ARMOUR (SWA) (WITH LEAD INNER SHEATH ON PB VARIANTS) . FOR USE IN
HAZARDOUS LOCATIONS.
INCORPORATING EC DECLARATION OF CONFORMITY TO DIRECTIVE 94/9/EC
CM
P
Do
cu
m
en
tN
o.
FI
40
2
Is
su
e
5
01
13
0518
Glasshouse Street • St. Peters • Newcastle upon Tyne • NE6 1BS
Tel: +44 191 265 7411 • Fax: +44 191 265 0581
E-Mail: [email protected] • Web: www.cmp-products.com
Notified Body: Sira Certification Service, Rake Lane, Chester CH4 9JN, England.
I, the undersigned, hereby declare that the equipment referred to herein conforms to the requirements of the ATEX Directive 94/9/EC and the following
standards:-
EN60079-0:2006, EN60079-1:2007, EN60079-7:2007, EN60079-15:2005, BS 6121:1989, EN50262:1998 (Amd 2001), EN61241-0:2004, EN61241-1:2004
Dr Geof Mood - Technical Director - (Authorised Person)
DUBAI
• HOUSTON • NEWCASTLE • SINGAPORE • SHANGHAI • PUSAN • PERTH
www.cmp-products.com
Ca
bl
e
Gl
an
d
Se
le
ct
io
n
Ta
bl
e
Logo’s shown for illustration purposes only. Please check certification for details
Cable
Gland
Size
Available Entry
Threads
Minimu
m
Thread
Length
Number
Of
Cores
Diameter
Over
Conductors
Maximum
Diameter
Over Lead
Sheath
Overall Cable
Diameter
Armour Wire Diameter
Across
Flats
Across
Corners
Ordering
Reference
(Brass Metric)
**
Standard
Option
Grooved Cone Stepped Cone
Metric
NPT
NPT
Max
Max
Min
Max
Min
Max
Min
Max
Max
Max
20S/16
M20
1/2”
3/4”
15.0
11
12.6
14.9
6.1
11.5
0.15
0.5
0.8
1.0
30.5
33.6
20S16PX2KREX1RA
20S
M20
1/2”
3/4”
15.0
11
12.6
14.9
9.5
15.9
0.15
0.5
0.8
1.25
30.5
33.6
20SPX2KREX1RA
20
M20
1/2”
3/4”
15.0
21
12.6
19.9
12.5
20.9
0.2
0.5
0.8
1.25
30.5
33.6
20PX2KREX1RA
25S
M25
3/4”
1”
15.0
38
17.5
21.0
14.0
22.0
0.2
0.6
1.25
1.6
37.5
41.3
25SPX2KREX1RA
25
M25
3/4”
1”
15.0
38
17.5
25.2
18.2
26.2
0.2
0.6
1.25
1.6
27.5
41.3
25PX2KREX1RA
32
M32
1”
1-1/4”
15.0
59
23.6
32.9
23.7
37.9
0.2
0.6
1.6
2.0
55.0
50.6
32PX2KREX1RA
40
M40
1-1/4”
1-1/2”
15.0
89
30.0
39.4
27.9
40.4
0.2
0.8
1.6
2.0
55.0
60.5
40PX2KREX1RA
50S
M50
1-1/2”
2”
15.0
115
36.6
45.7
35.2
46.7
0.2
0.8
2.0
2.5
60.0
66.0
50SPX2KREX1RA
50
M50
2”
2-1/2”
15.0
115
41.0
52.1
40.4
53.1
0.3
0.8
2.0
2.5
70.0
77.0
50PX2KREX1RA
63S
M63
2”
2-1/2”
15.0
140
47.9
58.4
45.5
59.4
0.3
0.8
2.0
2.5
75.0
82.5
63SPX2KREX1RA
63
M63
2-1/2”
3”
15.0
140
53.7
64.9
54.6
65.9
0.3
0.8
2.0
2.5
80.0
88.0
63PX2KREX1RA
75S
M75
2-1/2”
3”
15.0
140
59.9
72.8
58.0
72.1
0.3
0.8
2.0
2.5
89.0
97.9
75SPX2KREX1RA
75
M75
3”
3-1/2”
15.0
140
64.3
77.5
66.7
78.5
0.3
0.8
2.5
3.0
99.0
108.9
75PX2KREX1RA
90
M90
3-1/2”
3-1/2””
15.0
140
75.3
89.4
78.2
90.4
0.4
0.8
3.0
3.5
114.0
125.4
90PX2KREX1RA
100
M100
4”
-
15.0
200
85.6
100.5
86.1
101.5
0.4
0.8
3.15
4.0
133.0
146.3
100PX2KREX1RA
All dimensions in millimetres unless otherwise stated
Note:
Codes shown are for PX2K-REX glands, for PX2KW-REX or PX2KX-REX add “W” or “X” respectively, e.g. 20PX2KWREX1RA, 20PX2KXREX1RA
CABLE GLAND TYPES
CABLE GLAND TYPES
PX2K-REX, PX2KW-REX &
PX2K-REX, PX2KW-REX &
PX2KX-REX & VARIANTS
PX2KX-REX & VARIANTS
TECHNICAL DATA
CABLE GLAND TYPE
: PX2K-REX, PX2KW-REX & PX2KX-REX
INGRESS PROTECTION
: IP66, IP67, IP68, Type 4X; Oil Resistant II
PROCESS CONTROL SYSTEM
: BS EN ISO 9001
: ISO / IEC 80079-34:2011
HAZARDOUS AREA CLASSIFICATION
ATEX CERTIFICATION No
: SIRA 06ATEX1097X & SIRA 07ATEX4326X
ATEX CERTIFICATION CODE
:
II 2 GD Ex d IIC / Ex e II / Ex nR II / Ex tD A21 IP66
IEC Ex CERTIFICATION No
: IEC Ex SIR.06.0044X
IEC Ex CERTIFICATION CODE
: Ex d IIC / Ex e IIC / Ex nR II / Ex tD A21 IP66
CSA-US CERTIFICATION No.
: 2288626
CSA-US CERTIFICATION CODE
: Class I Div 1, 2, Groups A, B, C, D: Class II, Div 1, 2, Groups F and G; Class III, Div 1, 2;
Class I Zone 1 AEx d IIC / AEx e II
(Code details depends upon application - please see certificate)
INSTALLATION INSTRUCTIONS
Installation should only be performed by a competent person using the correct tools. Spanners should be used for tightening. Read all instructions
before beginning installation.
SPECIAL CONDITIONS FOR SAFE USE
1. The cable gland ranges shall only be used where the temperature, at the point of entry, is in the following ranges:
-60°C to +85°C.
2. The cable glands used for terminating braid cable are only suitable for fixed installations. Cables must be effectively clamped to prevent twisting
and pulling.
3. The entry component threads may need additional sealing to maintain the ingress protection ratings as applicable to the associated equipment to
which it is attached.
4. According to the CEC wiring code, connectors with metric threads are only suitable for Areas Classified in ZONES unless fitted with an approved
Metric to NPT thread conversion adaptor.
5. Wiring method for type of cables that can be used in Class I, Div. 1, 2, and Class I, Zone 1, 2, Classified Areas according to 60079-14 installation
wiring method restrictions.
6. Shipboard Cables are for use on Marine Platform or shipboards only and are subject to local authorities having jurisdiction on the installation.
ACCESSORIES
The following accessories are available from CMP Products, as optional extras, to assist with fixing, sealing and earthing :-
Locknut | Earth Tag | Serrated Washer | Entry Thread (I.P.) Sealing Washer | Shroud *
