31
 SYNC : In areas where the supply is at
60Hz, you can synchronize the
output phase of multiple cameras
using the power synchronization
function (Line-Lock) without using
a synchronization signal generator.
– INT : Internal Synchronization Type
– L/L : Power Synchronization Type, Line-lock
l Press the Function Setup switch.
l You can select a desired phase from 0 to 359 when select ‘phase’.
 MOTION DET : You can monitor activity more efficient with this feature allowing you to
observe movement of objects
in 8 different areas on the
screen, and the words
‘MOTION DETECTED’ appear
on the screen when
movement is detected..
1) When the SPECIAL menu screen is displayed, press the Up and Down buttons so that the arrow
indicates ‘MOTION DET’.
Notes
• When using AC power at 60Hz frequency, you can use the L/L type synchronization.
• When the power is DC 12V, the SYNC menu is fixed to the ‘INT’ mode.
