19
Camera functions and settings can be adjusted or changed by activating the OSD menu. When
the OSD menu is activated text will display on the monitor. The user can then move the cursor
to the desired function to change the setting.
Camera OSD Menu
SETUP Menu
LENS • DC MANUAL
EXPOSURE • BRIGHTNESS • SHUTTER • AGC
• SENS-UP • RETURN
WHITE BALANCE
• ATW • OUTDOOR • INDOOR
• MANUAL • AWC SET
SSDR • OFF • ON
BACKLIGHT • OFF • BLC • HLC
DNR3 • OFF • ON
DAY / NIGHT
• AUTO • COLOR • B/W
• EXTERN
SPECIAL
• IMAGE ADJ. • MONITOR • CAM TITLE
• SYNC • MOTION DET • PRIVACY
• COMM ADJ • LANGUAGE • RETURN
EXIT • SAVE • NOT SAVE • RESET
Settings can be adjusted using the joystick located on the back of the device.
Accessing the OSD Menu
WHEN SD CARD IS INSERTED,
YOU MUST POWER CYCLE.
You can do this by pushing the POWER
button on the long remote,
or by unplugging the power cord from the wall.
SD Card
16
GB
SD Card
2
GB
Camera OSD Joystick
