Document # 101522 0608 REV A ER 784 4
WARNING
When performing a cauterization or similar treat-
ment, the patient must be insulated from the metal
portions of the table by nonconductive material.
Failure to do so may result in electrical shock or
burns to the patient.
WARNING
Use 115 VAC, 60 Hz alternating current only. Failure
to do so may result in electrical shock to personnel
and will result in damage to the table.
WARNING
Do not use this table in an explosive or oxygen-
enriched atmosphere. Failure to do so may result
in serious personnel injury or death.
CAUTION
Do not use any power supply other than that
listed on the rating label (Figure 1). Failure to do
so may result in serious injury and/or equipment
damage.
SPECIFICATIONS
Power Cord.......................................................................
............ Extends 70 in. (Minimum) from table. 18 AWG / 3
............. conductor, SJT grey jacketed junior hard service
............with hospital plug
Type of protection against electrical shock …….. Class 1
.......................................................................... Grounded
Type of protection
against electrical shock …….. .................. B applied parts
Type of protection against ingress of water……. Ordinary
Type of protection against ingress of water for foot control..IPX1
Can accept paper rolls of
....................................................................18 in. x 3.0 in.
....................................................................21 in. x 3.0 in.
Certifications
* .................................UL6060-1; UL2601-1;
..........................IEC60601-1; CAN-CSA C22.2 No. 601.1
Transport and Storage Conditions:
Temperature Range......................................-20º to 150º F
Relative Humidity...........................................10% to 90%
Operating Conditions:
Temperature Range ........................................ 65° to 85°F
Relative Humidity...........................................10% to 90%
* ETL classified in the United States and Canada
per the following standards.
Weight of Table .....................................................550 lbs.
Load Rating (maximum):
Seat/Back .............................................................450 lbs.
Legrest (Flat & Kneeling) ......................................450 lbs.
Headrest ...............................................................100 lbs.
Back Section Range ...............0° (horizontal) to +85° ± 5°
Table Top Height Range ...........19 ± 0.5 in. to 40 ± 1.0 in.
Leg Section Range ............0° (horizontal) to 90° (vertical)
Table Top
Tilt Range ................ 0° (horizontal) to +30° ± 5° (foot up)
Dimensions:
Upholstered Headrest..................13 in. wide x 11 in. high
Upholstered Top ....................28.0 in. wide x 44.5 in. long
Upholstered
Leg Rest ....…………………16.5 in. wide x 11.25 in. high
Overall Length ..................................................69 in. long
With Headrest/
Footrest Extended ............................................90 in. long
Electrical Requirements
..................115 VAC nominal, 60 HZ, 5.8 amps maximum
Duty Cycle (10%)
................. 2 minutes on / 18 minutes off (motor run time)
ELECTRICAL REQUIREMENTS
CAUTION
This product has been evaluated with respect to
electrical shock, fire, and mechanical hazards only
in accordance with UL60601-1; IEC60601-1;
UL2601-1; CAN/CSA C22.2 No. 601.1
