HP Color LaserJet 4650 Printer series User Manual

Page 207

background image

5. Grasp the media by both corners and pull up.

6. Firmly lift the two green handles on either side of the fuser to disengage the fuser rollers.

7. Grasp the media by both corners and pull to remove it.

Note

If the media tears, make sure that all media fragments are removed from the paper path
before resuming printing. Do not reach into the fuser until it has cooled.

8. Firmly press down on the two green handles on either side of the fuser to re-engage the

fuser rollers.

ENWW

Clearing jams

193
