Chapter 3 3-5
Operating the Jukebox
Operating the Control Panel
Op
er
atin
g
th
e
Ju
kebo
x
The numbers below refer to the numbers in Figure 3-1 on the previous page.
NOTE Figure 3-2 shows the jukebox menus available using the control panel selection
buttons.
1 Swivel feature The control panel assembly may be rotated to face the
display (#3 below) toward the front or right side of the
jukebox. The front has the vertical window, the right
side has the mailslot.
2 Activity light Lit differently to indicate the following:
• Steady Green - power is on
• Flashing Green - an optical drive is being accessed
• Amber - a fault occurred
3 16-character
display Displays information about the current operation.
4 Selection
buttons Pressed to perform the following operations:
CANCEL cancels the current operation or choice
PREV scrolls the display choice backward by one
NEXT scrolls the display choice forward by one
ENTER selects the displayed choice
5 Power switch Used to power the jukebox on and off.
6 Mailslot Used to load and eject optical disks
