10 Specifications
55-inch (138.7-cm) models
LCD Panel Screen type 1387.80 mm Wide (55 inch) TFT (Thin Film Transistor) LCD (Liquid
Crystal Display) Panel.
Visible diagonal size : 1387.80 mm
Pixel pitch 0.630 mm (H) x 0.630 mm (V)
Video Signal Max resolution RGB : 1920 x 1080 @ 60 Hz
HDMI/ DisplayPort : 1920 x 1080 @ 60 Hz
It may not be supported depending on the OS or video card type.
Recommended resolution RGB : 1920 x 1080 @ 60 Hz
HDMI/ DisplayPort : 1920 x 1080 @ 60 Hz
It may not be supported depending on the OS or video card type.
Horizontal frequency 30 kHz to 83 kHz
Vertical frequency 50 Hz to 60 Hz
Synchronization type Separate Sync, Composite Sync, Digital
Input connector 15-pin D-Sub type, HDMI (digital), Component, RS-232C, LAN,
DisplayPort, USB
Power Rated voltage AC 100-240 V~ 50/60 Hz 1.3 A
Power consumption On Mode : 130 W Typ
Sleep Mode (if WOL is off) : ≤ 0.5 W
Sleep Mode (if WOL is on) : ≤ 2.0 W
Off Mode : ≤ 0.5 W
Environmental
conditions Operating Temperature
Operating Humidity
0°C to 40°C
10% to 80%
Storage Temperature
Storage Humidity
-20°C to 60°C
5% to 95%
Dimensions W x H x D, weight)
(no stand or speakers)
1244.4 mm x 719.9 mm x 82.2 mm
48.99 in x 28.34 in x 3.24 in
18.06 kg
39.82 lbs
(stand, no speakers) 1244.4 mm x 787.8 mm x 269.4 mm
48.99 in x 31.02 in x 10.61 in
20.2 kg
44.53 lbs
55-inch (138.7-cm) models 61
