Making connections
Connect various external devices to the ports on the display back panel.
1.
Find an external device you want to connect to your display shown on the following illustration.
2.
Check the connection type of the external device.
3.
Go to the appropriate illustration and check the connection details.
Item
Source
Reference
Item
Source
Reference
(1)
HD receiver
DisplayPort connection on page 39
Component connection on page 41
(4)
Speakers
Component connection on page 41
(2)
DVD
DisplayPort connection on page 39
Component connection on page 41
(5)
USB
Connecting to a USB on page 42
(3)
VCR
Component connection on page 41
(6)
Computer
DisplayPort connection on page 39
Connecting to the LAN on page 42
NOTE:
For sound, you must connect an optional speaker.
38
