● Configuration define an array of displays showing a single image (up to 25 DisplayPort and 6
RGB/VGA).
Auto Config: Sets to adjust the screen position, clock, and phase automatically. The displayed image
may be unstable for a few seconds while the configuration is in progress.
Position: Moving the screen position horizontally and vertically.
Size: Adjust the horizontal and vertical size of the screen taking into account the size of the bezel.
Natural: Allows the image to retain proportionality across the array by compensating for the width of
the mullion (the distance between the active display area to the active display area of the adjacent
display in the array).
Reset: Function to initialize and release Tile. All Tile setting are released when selecting Tile reset and
the screen returns to Full screen.
PIP/PBP Displays videos or photos stored in a USB device on a single display by dividing it into the main and sub
screens.
Option
Mode: Sets the type of secondary screen.
● *OFF: Disables the secondary screen.
● *PIP (Picture In Picture): Displays the secondary screen in the main screen.
● *PBP (Picture By Picture): Displays the secondary screen next to the main screen.
Position: Adjusts the position of the sub screen (top left, bottom left, top right, bottom right) The
default value is the bottom right.
Size: Adjusts the size of the sub screen (Size 0 to 10). The default size of PIP (Size: 0) is 480x270; the
maximum size 10 is 960x540.
NOTE: The Position and Size options are enabled only in PIP mode.
Key Lock Disenables or enables rear side control keys. If Key Lock is on, the display controls are disenable (rear
side key function).
Product/Service Info Displays the model name, software version, serial number, IP address, MAC address and home page.
Portrait Mode Rotate OSD clockwise (90°)
Standby Power Control Sets the option to keep EDID value when the monitor is turned off. It can be set to On or Off.
If you set it to On, the EDID value is kept when the monitor is turned off.
If you set it to Off, the EDID value is lost when the monitor is turned off.
If set to Off, the EDID value can be stored according to the Input and Model.
Tile Mode
This display can be tiled with additional displays to create a large tiled display.
● Off: When the Tile Mode option is disabled.
● 1x2: When using 2 displays.
32 Chapter 6 Customizing settings
