Using the ir receiver – HP LD5535 55-inch LED Digital Signage Display User Manual
Page 15
Item
Button
Description
(2)
1
Moves the selection up and down.
2
Adjusts the volume level.
3
Displays the current signal and mode. Press this button to adjust the screen automatically (RGB mode only).
4
Accesses the main menus, or saves your input and exits the menus.
5
Changes the input source.
6
Turns the power on or off.
Using the IR receiver
Allows a remote control sensor to be placed in a custom location.
NOTE:
You must apply the adhesive metallic label to secure IR receiver.
The magnetic IR receiver must be placed on the front or side of the display in the remote control line of sight.
Attach the metallic adhesive label to the desired position on the display. HP recommends that you attach the
label in the location as shown in the following image.
Using the IR receiver
5
