Displayport connection – HP LD5535 55-inch LED Digital Signage Display User Manual
Page 23
DisplayPort connection
Transmits digital video signal from your computer to the display. Connect the computer and the display with
a DisplayPort cable as shown the following illustration. Select Display IN. The audio in cable is not provided
with the display.
If you will be connecting this display to another display via DisplayPort (daisy chain), plug one end of a
second DisplayPort cable into the DP-OUT connector on the display and plug the other end of DisplayPort
cable into the DP-IN connector on the next display in chain. For more information, see
displays to one player on page 17
Back of the product
Connecting the display to a Digital Signage media player or computer
13
