Input label adjustment
Selecting input labeling
The digital inputs may be set to PC or DTV input labels (HDMI, DisplayPort or VOE). The PC input label allows
limited aspect ratio (16:9, 1:1 or 4:3). The DTV input label provides adjustment capabilities for zoom, Just
Scan, sharpness, color, and tint control.
The digital input labeling procedure (HDMI, DisplayPort or VOE inputs only).
1.
Press the INPUT button to access the input source list.
2.
Press the blue button to access the input label.
3.
Press the navigation buttons to scroll to one of the input sources
4.
Press the navigation buttons to scroll to an input label name, and then press OK.
Adjusting aspect ratio
CAUTION:
All models are not suitable for applications that exhibit static, stationary, or fixed images. Static
images may cause image retention damage that may appear as stains or watermarks on the screen. The
warranty does not cover displays that are in use for applications that exhibit static, stationary, or fixed
images for long periods or for 24-hours per day that result in image retention damage. To avoid image
retention damage, turn off the display when it is not in use or use a power management setting, if supported
by your system, to turn off the display when the system is idle.
NOTE:
You can also change the image size by accessing the main menus.
Just Scan mode operates when a video signal has resolution of 720p or higher.
MODE
Component
RGB
PC
DisplayPort
HDMI
ARC
DTV
PC
DTV
PC
16:9
o
o
o
o
o
o
Just Scan
o
x
o
o
o
o
1:1
x
o
x
o
x
o
4:3
o
o
o
o
o
o
Zoom
o
x
o
x
o
x
Cinema Zoom
o
x
o
x
o
x
