HP P2000 G3 FC/iSCSI MSA System User Guide 39
To connect the P2000 G3 FC/iSCSI MSA System to a server or HBA switch — using the controller’s iSCSI
host ports — select the appropriate qualified 1Gb option (see Quickspecs).
Single controller configuration
One server/one HBA/single path
Dual controller configurations
One server/one HBA/dual path
4Gbps 70m with 62.5μm fiber type X
150m with 50μm fiber type X
380m with 50μm fiber type X
2Gbps 150m with 62.5μm fiber type X
300m with 50μm fiber type X
500m with 50μm fiber type X
Table 5 Maximum cable lengths for 850nm Fibre Channel SFP transceivers
SFP data Representative FC cable types Cable performance code
Data rate MMF FC cable length designators OM1 OM2 OM3
6G b / s
6G b / s
S erver
S erver
6G b / s
6G b / s
6G b / s
6G b / s
S erver
S erver
