Business Copy XP user guide for the XP10000/XP12000 59
start the paircreate operations. To open the Paircreate window, select one or more SMPL volumes or PSUS
pairs in the Volume list on the BC main screen, right-click the selected volumes, and select Paircreate.
Figure 34 Paircreate window
The Paircreate window consists of the following components:
• ” Paircreate Volume List ” on page 59
• ” Copy Pace list ” on page 60
• ” Select MU list ” on page 60
• ” Select S-Vol box ” on page 60
• ” Buttons ” on page 61
• ” Creating L1 pairs ” on page 61
• ” Creating L2 pairs ” on page 62
Paircreate Volume List
The Volume List in the upper half of the Paircreate window displays the following information about the
P-VOL and S-VOL used for creating a pair:
NOTE: The S-VOL for each P-VOL is displayed only after being selected (using Set or Change).
• Port: Port ID (cluster and channel number) of the P-VOL.
• G-ID: Host group ID of the P-VOL.
• LUN: CU:LDEV of the P-VOL.
NOTE: An LDEV number ending with # (for example, 00:01#) indicates the LDEV is an external
volume.
• MU: MU number of the P-VOL.
• Status: Status of the P-VOL.
• Port: Port ID (cluster and channel number) of the first S-VOL of each volume pair.
• G-ID: Host group ID of the S-VOL.
