5 Installing a Monochrome Monitor

The HP NetServer LH Pro supports both color and monochrome monitors. The
NetServer is factory-configured for a color monitor. To configure the NetServer
for a monochrome monitor, you must change the J16 jumper setting on the system
board to the setting shown in Figure 5-1.

J16
Color = 1 - 2
Monochrome = 2 - 3

1 2 3

Figure 5-1. Monitor Settings on the System Board
