Command line 53
Item Description
Syntax add server-port-map
[Uplinkset=] [Network=]
[VLanID=] [Untagged=]
Parameters
ConnectionID
(required)
The reference ID an existing enet-connection associated with a profile and a
server port. The format of the ConnectionId is .
Network (required) The name of a valid network to which the mapping will be added. A network
can be configured once for every profile connection, and every profile
connection can be configured for a maximum of 28 networks.
Properties
Uplinkset
(optional)
The name of the shared uplinkset to use with the server port mapping. If the
domain setting SharedServerVLanId is set to "true", then the Uplinkset is a
required value.
VLanID (optional) The VLAN ID to be used for the mapping. Valid values include 1 to 4094. If the
uplinkset name is specified, then the VLanID property should not be specified,
because the server VLAN ID is forced to be same as the VLAN ID used when
adding the network to the shared uplinkset.
UntaggedD
(optional)
Enable or disable the network to handle untagged packets. Only one network in
an Ethernet network connection can be made to handle untagged packets. The
default value is "false". If a shared uplink set is being used, then the untagged
network is the same as the native network, if present, but any other network can
be configured to handle untagged packets.
Examples
->add server-port-map MyProfile:1 Network1 VLanID=100
Adds a new server port to dedicated network mapping
->add server-port-map MyProfile:2 RedNetwork
Uplinkset=MyUplinkSet1
Adds a new server port to shared network mapping
->add server-port-map MyProfile:3 GreenNetwork
Uplinkset=MyUplinkset1 UnTagged=true
Adds a new server port to shared network and label it as untagged
Item Description
remove server-
port-map
Remove a server port network mapping. This command cannot be used if the
domain setting VLanTagControl is set to "Tunnel".
Syntax remove server-port-map [Network=
Name>]
Parameters
ConnectionID
(required)
The reference ID of an existing enet-connection associated with a profile and a
server port. The format of the ConnectionId is: . "*" will
remove all server-port-map configurations from the domain
Network
(optional)
The name of an Ethernet network to which the mapping exists.
Examples
->remove server-port-map MyProfile:1 RedNetwork
Removes a server port network mapping
