Microprocessor reversing control assembly, Struthers-dunn – ADC UD-50 User Manual
Page 50
48
American Dryer Corporation
88 Currant Road / Fall River, MA 02720-4781
Illus. No.
Part No.
Qty.
Description
1
150301
6
#8-18 x 7/16” Phillips Pan Head TEK Screw
2
322808
1
Relay Box Cover Plate ONLY
3
137060
1
Arc Suppressor (A.S.) Board (3)
4
137013
4
Nylon Standoff
5
153002
2
5/16” Lock Washer
6
152004
2
5/16-18 Hex Nut
7
150108
4
#8-32 x 1/2” Pan Head Machine Screw
8
132404
1
Reversing Contactor - 208 Volt
132401
1
Reversing Contactor - 220/230 Volt
9
132416
2
Reversing Contactor Replacement Coil
(208 Volt - 60 Hz)
132415
2
Reversing Contactor Replacement Coil
(220/230 Volt - 60 Hz)
132407
2
Reversing Contactor Replacement Coil
(240 Volt - 50 Hz)
10
322807
1
Contactor Mounting Panel ONLY
11
151001
2
#8-32 Pal Nut
Microprocessor Reversing Control Assembly
Struthers-Dunn
