Basket (tumbler)/support assemblies – ADC UD-50 User Manual
Page 21
19
Telephone: (508) 678-9000
Fax: (508) 678-9447
Illus. No.
Part No.
Qty.
Description
1
800706
1
Basket (tumbler) ONLY without Felt Collar
800856
1
Stainless Steel Basket (tumbler) ONLY without Felt Collar
800806*
1
1-3/8” Non-Reversing Basket (tumbler)
and Support Assembly Complete
(includes illus. nos. 1 through 10)
800866*
1
1-3/8” Stainless Steel Non-Reversing Basket (tumbler)
and Support Assembly Complete
(includes illus. nos. 1 through 10)
800818*
1
1-3/4” Reversing Basket (tumbler)
and Support Assembly Complete
(includes illus. nos. 1 through 10)
800875*
1
1-3/4” Stainless Steel Reversing Basket (tumbler)
and Support Assembly Complete
(includes illus. nos. 1 through 10)
2
150309
40
#10-16 x 1/2” Hex Head TEK Crimptite Screw
3
301301
4
Basket (tumbler) Rib ONLY
301401
4
Stainless Steel Basket (tumbler) Rib ONLY
4
150500
1
5/16-18 x 3/4” Socket Button Head Screw
5
100902
4
5/16-18 x 31” Tie Rod
6
153001
4
5/16” Flat Washer
7
800606
1
1-3/8” Non-Reversing Basket (tumbler) Support ONLY
800615
1
1-3/4” Reversing Basket (tumbler) Support ONLY
8
152004
4
5/16-18” Hex Nut
9
153002
4
5/16” Lock Washer
10
153001
4
5/16” Flat Washer
11
116002
1
Felt Collar ONLY
---
401010
1
#847 Adhesive for Felt Collar
* Felt collar is not included and must be ordered separately.
Basket (Tumbler)/Support Assemblies
