45
Telephone: (508) 678-9000 Fax: (508) 678-9447
Steam Coil/Valve Assembly
Illus. No. Part No. Qty. Description
1 803500 1 Large Steam Rack
(for models mfd. with high pressure Only)
803501 1 Large Steam Rack
(for models mfd. with low pressure Only)
2 150300 6 #10-16 x 1/2” Hex Washer TEK Screw
3 165002 1 Large Steam Coil
(for models mfd. with high pressure Only)
165003 1 Large Steam Coil
(for models mfd. with low pressure Only)
4 142711 1 1” Closed Nipple
(for models mfd. with high pressure Only)
142713 1 1-1/4” Closed Nipple
(for models mfd. with low pressure Only)
5 165107 1 1” Motorized Steam Valve
(for models mfd. with high pressure Only)
165102 1 1-1/4” Steam Valve - 120 Volt
(for models mfd. with low pressure Only)
165103 1 1-1/4” Steam Valve - 230 Volt
(for models mfd. with low pressure Only)
